The outer spherical ball bearing is actually a variant of the deep groove ball bearing, characterized by its outer ring outer diameter surface being spherical, which can be matched into the corresponding concave spherical surface of the bearing seat to play a centering role.

A spherical bearing with a seat is a bearing unit that combines a rolling bearing with a bearing seat. Most outer spherical bearings are made into spherical outer diameters and installed together with bearing seats with spherical inner holes, with diverse structural forms, good universality and interchangeability.

At the same time, this type of bearing also has a certain degree of centering in design, is easy to install, and has a dual structure sealing device, which can work in harsh environments.

The bearing seat is generally cast into shape. Common seats include vertical seat (P), square seat (F), convex square seat (FS), convex circular seat (FC), diamond seat (FL), circular seat (C), slider seat, etc. (T).

The spherical bearing with a seat is divided into a bearing core and a bearing seat. In terms of nomenclature, it is called the bearing core plus the bearing seat. For example, the UC205 spherical bearing with a set screw and a vertical seat is called UCP205.

Due to its strong interchangeability, the outer spherical bearings with seats can be freely assembled into bearing seats of the same specification but different shapes.

Outer spherical ball bearing with vertical seat

Outer spherical bearing with square seat

Outer spherical ball bearing with diamond seat

Outer spherical ball bearing with convex circular seat

Outer spherical ball bearing with annular seat

Outer spherical ball bearing with slider seat

External spherical ball bearing with suspended seat

External spherical ball bearing with suspended seat

Outer spherical ball bearing with adjustable diamond seat

Outer spherical ball bearing with stamped seat

Outer spherical ball bearings with other seats

Outer spherical ball bearings can be divided into three categories based on the cooperation method with the shaft:

1、 The codes for the outer spherical ball bearings with top thread are UC200 series (light series), UC300 series (heavy series), and the deformation product UB (SB) 200 series;

2、 The designation of tapered outer spherical ball bearings is: UK200 series, UK300 series;

3、 The codes for eccentric sleeve outer spherical ball bearings are: UEL200 series, UEL300 series, SA200 series.
